Brand Name : DABA
Model Number : DBMQ-320IML
Max.web width ：320mm
Max.unwinding diameter ：600mm
Unwinding /Rewinding tension control： Magnetic powder brake
Max.Mechanical die-cutting speed ：260 cuts/min based on 30mm cutting stroke
Die-cutting range ：300*300
Web guiding system：Auto web guide system
Max.rewinding diameter：600mm
Power supply ：220V l phase
Dimension(l*w*h) : 2600x1350x1400mm
DBMQ-320A auto flatbed die cutter is suitable for die cutting adhesive paper label, dacron film label and laser anti-false label. It cuts label materials into shape required for a designated shape design with high precison.
- The machine is splitted style flat to flat high precision die cutting .
- Pulling materials and cutting is controlled by computer.
- Two sides and a line are tracked by three photoelectric sensors.
- Tracking、die cutting 、collecting waste、adhesive label can be processed in the same time.
- It’s very suitable for paper adhesive label ,silk screen label and so on.
Product Model | DBMQ-320A | DBMQ-420A |
Max. web width(mm) | 320 | 420 |
Max. unwinding diameter(mm) | Φ600 | Φ600 |
Independent Unwinding(mm) | Φ1000 | Φ1000 |
Unwinding tension control | Friction plate brake | |
Die-cutting range(mm) | 300*350 | 400*400 |
Max. Mechanical die-cutting | 200 cuts/min based on 15mm cutting stroke | |
Web guiding system | Photoelectric eye sensor EPC*2 | |
Max. rewinding diameter(mm) | Φ600 | |
Rewinding tension control | Friction plate brake | |
Power supply | 220V 1 phase | 380V 3 phase |
Main motor power(kw) | 3 | |
Total motor power(kw) | 5 | |
Optional Functions
